Train your first Neural Network for Named Entity Recognition

Natural Language Processing Aug 15, 2021

Named Entity Recognition or simply, NER is an information extraction technique used in search efficiency, recommendation engines, customer service, automatic trading, and many more. It seeks to locate & classify named entities mentioned in unstructured text into pre-defined categories such as organizations, proper nouns, locations, medical codes, time expressions, quantities, monetary values, percentages, etc.

Photo by Jon Tyson / Unsplash

In this tutorial, we are going to train a BiLSTM network with a NER dataset. This is the extract from GMB corpus which is tagged, annotated and built specifically to train the classifier to predict named entities such as name, location, etc.

Let's get into it.

Step 1: Load and preprocess the dataset

We will be doing following preprocessing operations:

  1. Fill NA (null values) with ffill
  2. Tokenize words in each sentence to a token_id
  3. Pad each sentence to length: max_len in order to make up for training through BiLSTM network
  4. One-hot encode the entity mapping to make up for our cost computation at the end of the network.
data = pd.read_csv('../input/entity-annotated-corpus/ner_dataset.csv', encoding= 'unicode_escape')
data.head()

def get_dict_map(data, token_or_tag):
    tok2idx = {}
    idx2tok = {}

    if token_or_tag == 'token':
        vocab = list(set(data['Word'].to_list()))
    else:
        vocab = list(set(data['Tag'].to_list()))

    idx2tok = {idx:tok for  idx, tok in enumerate(vocab)}
    tok2idx = {tok:idx for  idx, tok in enumerate(vocab)}
    return tok2idx, idx2tok


token2idx, idx2token = get_dict_map(data, 'token')
tag2idx, idx2tag = get_dict_map(data, 'tag')

data['Word_idx'] = data['Word'].map(token2idx)
data['Tag_idx'] = data['Tag'].map(tag2idx)

data_fillna = data.fillna(method='ffill', axis=0)
data_group = data_fillna.groupby(['Sentence #'],as_index=False
                                )['Word', 'POS', 'Tag', 'Word_idx', 'Tag_idx'].agg(lambda x: list(x))

Step 2: Partition the dataset into Train, Validation & Test set

def get_pad_train_test_val(data_group, data):
    n_token = len(list(set(data['Word'].to_list())))
    n_tag = len(list(set(data['Tag'].to_list())))

    tokens = data_group['Word_idx'].tolist()
    maxlen = max([len(s) for s in tokens])
    pad_tokens = pad_sequences(tokens, maxlen=maxlen, dtype='int32', padding='post', value= n_token - 1)

    tags = data_group['Tag_idx'].tolist()
    pad_tags = pad_sequences(tags, maxlen=maxlen, dtype='int32', padding='post', value= tag2idx["O"])

    n_tags = len(tag2idx)
    pad_tags = [to_categorical(i, num_classes=n_tags) for i in pad_tags]


    train_tokens, test_tokens, train_tags, test_tags = train_test_split(pad_tokens, pad_tags, test_size=0.1, train_size=0.9, random_state=2020)

    print(
        'train_tokens length:', len(train_tokens),
        '\ntest_tokens length:', len(test_tokens),
        '\ntrain_tags:', len(train_tags),
        '\ntest_tags:', len(test_tags)
    )

    return train_tokens, test_tokens, train_tags, test_tags

train_tokens, test_tokens, train_tags, test_tags = get_pad_train_test_val(data_group, data)

Step 3: Build the Model

def get_bilstm_lstm_model():
    model = Sequential()


    model.add(Embedding(input_dim=input_dim, output_dim=output_dim, input_length=input_length))


    model.add(Bidirectional(LSTM(units=output_dim, return_sequences=True, dropout=0.2, recurrent_dropout=0.2), merge_mode = 'concat'))


    model.add(LSTM(units=output_dim, return_sequences=True, dropout=0.5, recurrent_dropout=0.5))


    model.add(TimeDistributed(Dense(n_tags, activation="relu")))

    model.compile(loss='categorical_crossentropy', optimizer='adam', metrics=['accuracy'])
    model.summary()

Step 4: Training

def train_model(X, y, model):
    loss = list()
    for _ in range(25):
        # fit model for one epoch on this sequence
        hist = model.fit(X, y, batch_size=1000, verbose=1, epochs=1, validation_split=0.2)
        loss.append(hist.history['loss'][0])
    return loss
model_bilstm_lstm = get_bilstm_lstm_model()

results = pd.DataFrame()
results['with_add_lstm'] = train_model(train_tokens, np.array(train_tags), model)

Step 5: Evaluation

plt.plot(results['with_add_lstm'])
plt.xlabel('Epochs')
plt.ylabel('Loss')
Loss vs Epochs Plot
text = nlp(
    'Jim bought 300 shares of Acme Corp. in 2006. And producing an annotated block of text that \
    highlights the names of entities: [Jim]Person bought 300 shares of \
    [Acme Corp.]Organization in [2006]Time. In this example, a person name consisting \
    of one token, a two-token company name and a temporal expression have been detected \
    and classified.State-of-the-art NER systems for English produce near-human performance. \
    For example, the best system entering MUC-7 scored 93.39% of F-measure while human \
    annotators scored 97.60% and 96.95%.[1][2]')


displacy.render(text, style = 'ent', jupyter=True)
Identified Entities mapped to their respective classes

[Optional]

Checkout the public notebook with all the above implementation:

[Bonus]

This blog is focused as a short tutorial, checkout the below tutorial for detailed explanations:

Named Entity Recognition (NER), Meeting Industry’s Requirement by Applying state-of-the-art Deep…
Few years ago when I was working as a software engineering intern at a startup, I saw a new feature in a job posting web-app. The app was able to recognize and parse important information form the…

Cheers!
